A collection of plans showing Nelson's famous flagship as she was at the Battle of Trafalgar on 21st October 1805, with detailed photographs and historical notes.
The plans presented here were based on the original Admiralty drawings and from dimensions taken on the ship. Basil Lavis who made the drawings took great care to make them as accurate as possible. For the convenience of model makers, the plans are all printed to fixed scales as stated beside each drawing. A colour scheme, compiled by Basil Lavis, is given. All photographs were taken by David R MacGregor.
